Altimexor Metal
Altimexor Metal
H-beam is a type of economical section and high-efficiency section with optimized cross-sectional area distribution and a superior strength-to-weight ratio. Named after its "H" shaped section, all parts are arranged at right angles. This provides strong bending resistance, simple construction, cost savings, and a lightweight profile, making it a preferred choice in structural engineering.
| Technical Specifications | |
|---|---|
| Grade | Q235B, SM490, SS400, Q345B, G300, G350, S275JR, S355JR |
| Standard | GB, ASTM, JIS, SUS, DIN, EN etc. |
| Technique | Hot rolled / Cold rolled |
| Application | Civil and Industrial Building Structures |
| Delivery Time | About 7-15 days |
| Payment | 30% T/T Advance + 70% Balance before shipment |
| Size (MM) h*b*tw*t | Weight (KG/M) | Size (MM) h*b*tw*t | Weight (KG/M) |
|---|---|---|---|
| 100*50*5*7 | 9.54 | 300*150*6.5*9 | 37.3 |
| 100*100*6*8 | 17.2 | 294*302*12*12 | 85.0 |
| 125*60*6*8 | 13.3 | 300*300*10*15 | 94.5 |
| 125*125*6.5*9 | 23.8 | 300*305*15*15 | 106.0 |
| 150*75*5*7 | 14.3 | 340*250*9*14 | 79.7 |
| 200*100*5.5*8 | 21.7 | 400*200*8*13 | 66.0 |
| 250*250*9*14 | 72.4 | 400*400*13*21 | 172.0 |
H-beams are primarily categorized into ordinary, light, and wide flange types. Characterized by parallel legs and non-oblique interiors, wide flange I-beams (H-beams) are rolled on universal rolling mills, providing significant economic and structural advantages.
With over 15 years of expertise, we provide a comprehensive range of steel products including angles, channels, plates, stainless steel, and PPGI coils. Our commitment to excellence has expanded our footprint to over 30 countries across South America, Africa, and the Middle East.
